◎ Filling liquid level ##: Filling liquid level error reaches ±2mm, which is superior to the industry standard.
◎ High work efficiency: The variable frequency speed control of ## is adopted to adjust the output at will within 1,000-4,500 bottles/hour.
◎ Large adjustment scope of bottle height: The height of bottle is within 100-380mm, which can be adjusted conveniently and randomly at any time. The bottle height error can automatically adapt.
◎ No fluid loss and leakage: It is sealed strictly, and doesn't cap and spray liquid in case of bottle breakage and leakage and no bottle.
◎ Automatic protection: Thumbwheel of bottle feeding and delivery are equipped with overload clutch protection device, and automatically shut down for alarm in case of abnormal conditions.
◎ Compliance with hygienic standard: Various sealing elements adopt imported (joint venture) components such as polytetrafluorethylene, silicone rubber, etc., meet the sanitary filling requirements of food and can be applied in hot filling.
◎ Soft starting: The variable frequency speed regulating device of ## is applied and makes the whole machine free from impact force in startup. The running speed is from the low to the high to avoid the machine from damage by broken bottles.
◎ Liquid flows down along the bottle wall in filling to effectively restrain the form generated when liquid impacts the bottom of the bottle.
◎ Filling valve is easily disassembled and is convenient for cleaning.
Technical parameters: 750mm/bottle/hour
|
Model |
Number of filling bottles |
Number of capping bottles |
Productivity |
Whole power |
Appearance dimension |
|
GZP6-6—1 |
6 |
6 |
1000-2000 box/hour |
2.2kw |
2600 X 1380 X 2200mm |
